Descriptions
The rope can be made of polypropylene，polyester and nylon multifilament in twisted way, Use 100% virgin raw material and has high quality,in the general,the polypropylene material is the most common,used in marine ships for fishing or mooring.
Use For Marine, Fishing Net, Ship Mooring, Agriculture, Gardening, Aquaculture, and Outdoor
Techinical sheet
SIZE | PP-Multi Rope (ISO 2307-2010) | Nylon Rope (ISO 2307-2010) | Polyester Rope (ISO 2307-2010) | |||||
Dia | Dia | Cir | WEIGHT | MBL | WEIGHT | MBL | WEIGHT | MBL |
(mm) | (inch) | (inch) | (kgs/220m) | (kgs or tons) | (kgs/220m) | (kgs or tons) | (kgs/220m) | (kgs or tons) |
4 | 5/32 | 1/2 | 1.32 | 200kgf | 2.31 | 320kgf | 2.60 | 295kgf |
5 | 3/16 | 5/8 | 2.45 | 290 | 3.60 | 500 | 4.10 | 400 |
6 | 7/32 | 3/4 | 3.75 | 380 | 4.95 | 750 | 6.00 | 565 |
7 | 1/4 | 7/8 | 5.10 | 530 | 6.70 | 1,020 | 8.20 | 770 |
8 | 5/16 | 1 | 6.60 | 680 | 8.80 | 1,350 | 10.00 | 1,020 |
9 | 11/32 | 1-1/8 | 8.10 | 890 | 11.20 | 1,700 | 13.50 | 1,270 |
10 | 3/8 | 1-1/4 | 9.90 | 1,050 | 13.60 | 2,080 | 16.70 | 1,530 |
12 | 1/2 | 1-1/2 | 14.30 | 1,500 | 19.60 | 3,000 | 24.20 | 2,270 |
14 | 9/16 | 1-3/4 | 20.00 | 2,030 | 27.00 | 4,100 | 32.60 | 3,160 |
16 | 5/8 | 2 | 25.30 | 2.75Ts | 35.00 | 5.30Ts | 43.00 | 4.10Ts |
18 | 3/4 | 2-1/4 | 32.50 | 3.20 | 44.00 | 6.70 | 54.00 | 5.15 |
20 | 13/16 | 2-1/2 | 40.00 | 4.15 | 54.00 | 8.30 | 67.00 | 6.40 |
22 | 7/8 | 2-3/4 | 48.40 | 4.95 | 66.00 | 10.00 | 81.00 | 7.60 |
24 | 1 | 3 | 57.00 | 5.85 | 78.00 | 12.00 | 96.00 | 9.10 |
26 | 1-1/16 | 3-1/4 | 67.00 | 6.70 | 92.00 | 14.00 | 113.00 | 10.70 |
28 | 1-1/8 | 3-1/2 | 78.00 | 7.80 | 107.00 | 15.80 | 131.00 | 12.20 |
30 | 1-1/4 | 3-3/4 | 89.00 | 9.00 | 122.00 | 17.80 | 150.00 | 13.70 |
32 | 1-5/16 | 4 | 101.00 | 10.20 | 139.00 | 20.00 | 171.00 | 15.70 |
